F3015T cnc laser cutting and engraving machine large laser cutting machine for metal sheet and tube

  • 1 - 1 Sets
    $100,000.00
  • 2 - 2 Sets
    $95,000.00
  • >=3 Sets
    $90,000.00
Model Number:
F3015T
Power(W):
1000w
Customization:
Customized packaging (Min. Order: 1 Sets)
Report Suspicious Activity
Overview
Quick Details
Application:
Laser Cutting
Condition:
New
Applicable Material:
Metal
Laser Type:
Fiber Laser
Cutting Area:
3000*1500mm
Cutting Speed:
25m/min
Graphic Format Supported:
AI
Cutting Thickness:
27mm
CNC or Not:
Yes
Cooling Mode:
Water Cooling
Control Software:
Bodorpro
Place of Origin:
China
Brand Name:
bodor
Certification:
CCC, CE, GS, ISO, UL, FDA
Laser Source Brand:
IPG/MAX
Laser Head Brand:
bodorgenius
Control System Brand:
bodorpro
Key Selling Points:
cast iron bed
Warranty:
3 years
After-sales Service Provided:
Online support, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Engineers available to service machinery overseas
Applicable Industries:
Building Material Shops, Manufacturing Plant, Farms, Advertising Company, industry
laser type:
fiber laser
Cooling Way:
Water Cooling
Laser Power:
1000W/2000W
U-axis max.moving speed:
30m/min
X/Y/U-axis positioning accuracy:
0.03mm
X/Y/U-axis repositioning accuracy:
0.02mm
Min. Edge Length:
≥20mm
Max. Outer Circle Diameter:
≤200mm
Supply Ability
Supply Ability:
30 Set/Sets per Month
Packaging & Delivery
Packaging Details
standard wood case.
Port
Qingdao
Video Description

Coconut shell laser cutting machine large format tailoring laser cutting machine laser cutting machine

laser cutting machine Features

BCL-FB Fiber sheet metal laser cutting machine adopts most sophisticated fiber laser, combining self-design Gantry CNC machine and high strength welding body. After high temperature annealing and precision machining by large CNC milling machine, it has good rigidity and stability with imported high precision and fast speed, linear guide drive. Aluminum beam, advanced heat treatment process, high strength, light weight, good rigidity. It is mainly for cutting sheet metal below 6mm in high speed and high precision. Fiber laser has a series of advantages, such as high beam quality, high brightness, high conversion rates, maintenance-free, stable and reliable operation of low cost and small size, etc. Air-assisted cutting is the most advanced level of laser cutting, which is particularly suitable for stainless steel, alloy steel, copper, titanium and other metal materials' precision cutting. It is widely used in metal products, hardware, precision machinery, auto parts, glasses, jewelry, nameplate, electronics, toys, advertising and other industries.
Advantage of Fiber laser cutting machine:
1. Excellent path quality: Smaller laser dot and high work efficiency, high quality.
2. High cutting speed: cutting speed is 2-3 times than same power CO2 laser cutting machine.
3. Stable running: adopt top world import fiber lasers, stable performance, key parts can reach 100,000 hours;
4. High efficiency for photoelectric conversion: Compare with CO2 laser cutting machine, fiber laser cutting machine have three times photoelectric conversion efficiency.
5. Low cost: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine.
6. Low maintenance: fiber line transmission no need reflect lens, save maintenance cost;
7 Easy operations: fiber line transmission, no adjustment of optical path.

laser cutting machine Applications
Applied in sheet metal processing, aviation, spaceflight, electronics, electrical appliances, subway parts, automobile, machinery, precision components, ships, metallurgical equipment, elevator, household appliances, gifts and crafts, tool processing, adornment, advertising, metal foreign processing various manufacturing processing industries.

Mainly used for cutting Mild steel, silicon steel, stainless steel, aluminum alloy, titanium alloy, galvanized steel sheet, pickling board, aluminium zinc plate, copper and many kinds of metal materials and so on.
laser cutting machine Technical Parameter
ModelF3015TF4020TF6020T
Working Area3000*1524mm4000*2000mm6100*2000mm
Laser Output Power4000w/3000w/2000w/1500w/1000w
Effective Pipe Cutting DiameterΦ20-Φ360mm
Effective Square Tube Cutting Diameter20*20-260*260mm
Rectangular tubeMin. Edge Length≥20mm
Max. Outer Circle Diameter≤360mm
Effective Pipe Cutting Length3m/6m
X/Y/U-axis positioning accuracy0.05mm
X/Y/U-axis repositioning accuracy0.03mm
X/Y-axis Max. linkage speed140m/min100m/min
U-axis max.moving speed30m/min
Machine detail
Package and transport
